Z1100

The Z1100 series is a thin design with only 10mm but have strong torque up to 10kg-cm, which is suitable for the glider with high speed flying. Its amazing stability is certified by the flying of the fast speed 870km/hr.

Servo
Operating voltage 4.5 ~ 8.4 V DC Volts
Max. torque 92.1 Ncm (130.5 oz-in) (9.4 kg-cm)
Continuous torque 29.4 Ncm (41.6 oz-in) (3.0kg-cm)
Weight 34.31 g (1.21 oz)
Max. Travel angle 120°±0.5° (default)
Signal Standard : PWM / DroneCAN (UAVCAN V.0) Custom : RS232 / RS485
Motor Brushless motor
Gear train Metal Alloy Gear
Case 6061 AluminumCNC Casing (Anodized)
Position sensor Hall Effect Sensor
